This project was built and designed by Tyler from DIYTyler.
Tyler kicks off a full DIY kitchen cabinet build by breaking down plywood sheets into the parts needed for cabinet boxes, doors, and toe kicks. The project uses a mix of pre-finished plywood in several thicknesses along with raw hardwood for the door panels, and Tyler walks through how he organizes and tracks the hundreds of individual pieces required for a whole-kitchen build.
Watch the full video and subscribe to DIYTyler:
Material Selection and Shop Setup
Tyler starts by explaining the different plywood types he’s using throughout the build, including pre-finished panels with a protective UV coating on both sides and thinner panels for door backing. He also has raw hardwood plywood set aside specifically for the visible door panels, giving the kitchen a mix of durability and natural wood appearance where it matters most.
The table saw becomes the central tool for this phase of the project since all the material is flat sheet goods. Tyler installs a riving knife with a dust shield attachment to help control the mess that comes from cutting so much sheet material, noting that dust collection becomes especially important when breaking down this much plywood.
Breaking Down the Sheets
Rather than jumping around between different cuts, Tyler works in batches, cutting all the long rip cuts first before moving on to crosscuts. This sequential approach helps him stay organized despite the sheer number of parts needed for a full kitchen’s worth of cabinets.
For crosscutting the long panels to width, Tyler switches to a track saw instead of trying to wrangle full sheets through the table saw. He explains that cutting an eight-foot board hanging off the side of a table saw isn’t a safe way to work, so the track saw becomes the safer, more practical choice for these particular cuts.
To keep everything organized, Tyler develops a labeling system using letters and numbers for each piece as it’s cut. With potentially thousands of individual parts in the full kitchen plan, this kind of tracking system becomes essential for knowing exactly which piece is which once the color-coded cut sheet no longer applies to the actual lumber.
Dialing In Repeat Cuts
Tyler makes good use of his table saw fence system’s stop blocks, which let him lock in a specific measurement and return to it repeatedly without having to remeasure every time. This becomes especially useful when switching back and forth between two common measurements throughout the cutting process, since the stops can be flipped up out of the way or back down into position as needed.
For crosscutting operations, Tyler builds a simple shop-made jig using an assembly table, a squared fence, and a stick-on tape measure zeroed at the blade line. This setup allows him to slide a track saw along the fence for consistent, repeatable crosscuts without having to measure and mark every single piece individually, saving significant time given the volume of parts involved.
Working Around the Grain
Once Tyler starts cutting into the raw hardwood plywood for the door panels, he notices the material doesn’t glide across the saw table as smoothly as the UV-coated panels did. To solve this, he applies a carbon-based lubricant to the saw table, which helps the raw wood slide more easily and reduces the risk of scratches during the cutting process.
While making these cuts, Tyler discovers he can rotate some of the door panel layouts compared to his original digital cut sheet, allowing him to fit more parts onto fewer sheets of quarter-inch plywood. It’s a good reminder that real-time adjustments on the shop floor can reveal material-saving opportunities that aren’t always obvious in a digital cutting plan.
Joinery Decisions for Strength
For joining the cabinet base to the sides, Tyler opts for dado joints rather than simpler alternatives, reasoning that since the plywood is already prepped and ready, adding a true wood-to-wood glue joint will result in a stronger, more durable cabinet overall. Getting the fit right takes some trial and error, aiming for a joint that’s snug enough to hold pieces together without forcing them, but not so tight that assembly becomes difficult.
Because the dado cuts are directional, Tyler has to be careful about pairing panels correctly before cutting, since the end panels can’t be flipped once the joints are cut. He also plans out which parts need through-cuts versus rabbet joints, distinguishing between the front-facing cabinet bases that need full dado cuts and the back cabinet panels that will use rabbet joints instead for a different style of connection.
The Payoff of a DIY Kitchen
Tyler wraps up by revealing that the finished kitchen, which had been in daily use for about a year by the time this video was released, cost a fraction of what a comparable custom kitchen would typically run. Between the plywood and finishing materials, the total investment came in well under what professionals quoted for similar work, proving that a well-planned DIY approach can deliver both significant savings and better material quality.
See Tyler’s plans here: https://www.diytyler.com/shop/
Matt’s Take
These are my personal thoughts and tips based on my own experience in the shop. This section is not written, reviewed, or endorsed by the original creator of this project.
Breaking down a whole kitchen’s worth of plywood is one of those jobs that looks simple until you’re staring at a cut list with hundreds of parts on it. Tyler’s approach of batching all his rips before moving to crosscuts is a solid habit to build early on. It cuts down on fence changes and keeps you from second-guessing a setting you already dialed in an hour ago.
His call to switch to a track saw for crosscutting full sheets is worth repeating to anyone newer to sheet goods. Trying to balance an 8-foot panel on a table saw with most of it hanging off the side is how kickback and blown cuts happen. A track saw, or even a simple straightedge clamped down, gives you a much safer and more controlled cut on anything that large.
The carbon lubricant trick for raw hardwood plywood is a good one to file away. Pre-finished panels already have a slick coating, but raw material can grab and drag across cast iron, which raises the odds of tear-out or a burn mark. A little paste wax or a dedicated table lubricant solves that problem quickly and also helps protect the saw table from rust.
On the joinery side, dadoes over simple butt joints are the right call for base cabinets that need to hold weight for decades. Just remember that once you cut a dado, that panel’s orientation is locked in, so dry-fitting and labeling parts before any irreversible cuts is cheap insurance against a wasted sheet of plywood.
