This project was built and designed by Jason from PatriotDIY.
This plyometric jump box offers three different height options in a single build, making it a versatile tool for training speed, agility, and lower body strength. Jason designed this version for his son, a baseball player, but the same design works well for anyone looking to add a training tool to a home gym without paying the high prices that commercial versions often carry.
Watch the full video and subscribe to PatriotDIY:
Design and Versatility
The standout feature of this build is that a single box can be flipped onto three different sides to provide three separate jump heights. This makes it ideal for beginners who can start on the lowest setting and gradually work their way up as strength and confidence improve.
Rather than simply screwing plywood panels together, Jason designed each side with interlocking tabs, similar to puzzle pieces. This approach ensures that no matter which side is facing up, the box remains fully supported on every face, giving it enough strength to handle everything from a child’s weight up to a full grown athlete.
Cutting the Panels and Tabs
The box comes together using less than a full sheet of plywood, cut into pairs of matching panels of three different sizes. Jason used a table saw and track saw for his cuts, but noted that anyone without access to those tools can have a home improvement store cut the panels from a provided cut sheet.
Once the panels were cut, the tabs were marked out by dividing each edge into thirds, using a spare piece of plywood as a guide to keep the tab widths consistent across all the pieces. This step is key to making sure everything interlocks properly during assembly.
A band saw was used to cut the tabs with precision, though Jason pointed out that a jigsaw works just as well, especially for cuts that fall in the middle of a panel. Combining a jigsaw for relief cuts with a band saw for the final straight lines is another option for getting clean results.
Assembly
With all the tabbed pieces cut, assembly started with wood glue applied to the interlocking tabs before the panels were pieced together. Corner clamps and a band clamp helped keep everything square while the glue set, and a brad nailer locked the pieces in place temporarily.
The bottom panel was installed the same way, with glue along the mating edges and a few taps with a hammer to seat it into place. A center support was added inside the box using pocket hole joinery for extra rigidity, though Jason mentioned this step isn’t strictly necessary and could be skipped or replaced with screws or nails if a pocket hole jig isn’t available.
Once the top panel was glued and tapped into place, the entire box was reinforced by countersinking screws into each tab. This step locks in the strength of the interlocking design and ensures the box can handle repeated impact over time.
Finishing Touches
Hand holes were added to the sides using a Forstner bit to drill starter holes, followed by a jigsaw to complete the cutout. Jason recommended cutting these holes before assembly rather than after, since it’s much easier to access the panels while they’re still flat.
Any small gaps left from assembly were filled with wood filler before sanding the entire box smooth. A round-over bit was then used on all the edges, including the hand holes, to eliminate sharp corners and make the box more comfortable to handle and transport.
As a final touch, Jason used stencils and spray paint to mark the height measurements directly on the sides of the box. This small detail makes it easy to identify which side is which at a glance, which is especially helpful for younger athletes still working their way up in height.
A Practical Build for Any Home Gym
This plyo box demonstrates how a thoughtful joinery approach can turn a simple plywood box into a sturdy, multi purpose training tool. The interlocking tab design adds strength that a basic butt-jointed box simply can’t match, while the three-in-one height option makes it useful for athletes at very different stages of training.
For anyone looking to save money over a store bought version, this build offers a straightforward way to get a durable, adjustable piece of equipment using minimal materials. Jason’s plans, linked in the original video description, offer a helpful reference for anyone wanting to replicate the exact dimensions and layout.
See Jason’s plans here: https://bit.ly/4wBh2a2
Matt’s Take
These are my personal thoughts and tips based on my own experience in the shop. This section is not written, reviewed, or endorsed by the original creator of this project.
Plyo boxes take a beating, so the joinery choice here really matters. Interlocking tabs distribute impact across the whole panel instead of concentrating stress on a few screws like you’d get with a basic butt joint. If you’re building something similar and want to skip cutting tabs, pocket screws with glue blocks in every corner can get you a comparable level of strength, just with a little more visible hardware.
Plywood choice is worth thinking about too. Baltic birch or a good quality cabinet-grade plywood will hold up a lot better under repeated jumping impact than construction-grade plywood, which can delaminate over time with that kind of stress. If weight matters for moving the box around, 3/4″ is usually plenty for the panels, with maybe a thicker or reinforced landing surface on top.
On the safety side, plyo boxes are one of those tools where sanding and rounding over edges isn’t just for comfort, it actually matters for injury prevention since these get used at speed and sometimes with less than perfect landings. A round-over bit is a great call, and it’s worth double checking that the top edges especially have zero sharp corners since that’s where hands and shins are most likely to make contact.
For anyone without a band saw or track saw, a circular saw with a straightedge guide can also get clean enough panel cuts for this kind of project, especially if a home improvement store handles the initial breakdown of the sheet goods.
